Canon XF105 User Manual

85
Special Recording Modes
Special Recording Modes
The camcorder features 4 special recording modes.
Interval recording ([Interval Rec]): The camcorder will automatically record a pre-defined number of frames at a
pre-defined interval. This mode is suitable for recording subjects with little movement, such as natural
surroundings or plants.
Frame recording ([Frame Rec]): The camcorder will record a pre-defined number of frames every time you press
the START/STOP button. This mode is suitable for recording stop motion animation.
Slow & fast motion recording ([Slow & Fast Motion]): This mode allows you to change the shooting frame rate to
achieve a slow motion or fast motion effect during playback.
Pre-recording ([Pre Rec]): The camcorder will start recording approximately 3 seconds before you press the
START/STOP button. This is especially useful when it is difficult to predict when to start recording.
Interval Recording Mode
Set the interval and number of frames in advance. Sound is not recorded
in this mode. This mode is not available if [J Other Functions] [Bit
Rate/Resolution] is set to [35 Mbps 1440x1080].
Configuring Interval Recording Mode
1 Open the [Interval] submenu.
[J Other Functions] [Interval Rec] [Interval]
2 Select the desired interval and then press SET.
• See the following table for the available intervals.
3 Select [Rec Frames], select the desired number of frames and then
press SET.
• Available options are 2, 6 and 12.
Available Intervals*
* In the camcorder’s menu, seconds are indicated by [sec] and minutes are indicated by
[min].
Activating Interval Recording Mode and Recording
1 Open the [Special Rec] submenu.
[J Other Functions] [Special Rec]
2 Select [Interval Rec] and then press SET.
• [INT STBY] appears at the top of the screen (with [INT] flashing).
3 Press the START/STOP button to begin recording.
• The camcorder automatically records the set number of frames at the set interval.
• The tally lamps illuminate.
• [INT STBY] changes to [N INT REC] while recording frames and [N INT STBY] while between intervals.
Operating modes:
1 sec 2 sec 3 sec 4 sec 5 sec 6 sec 7 sec 8 sec 9 sec
10 sec 15 sec 20 sec 30 sec 40 sec 50 sec 1 min 2 min 3 min
4 min 5 min 6 min 7 min 8 min 9 min 10 min
[J Other Functions]
[Interval Rec]
[Interval]
[1 sec]
[J Other Functions]
[Interval Rec]
[Rec Frames]
[2]
[J Other Functions]
[Special Rec]
[Off]
COPY

Canon XF105 Specifications

General

Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/1.3 \
Effective megapixels (image)	2.07 MP
Filter size	58 mm
Digital zoom	- x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	4.25 - 42.5 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Minimum aperture number	1.8
Focal length (35mm film equivalent)	30.4 - 304 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	CF, SD
Maximum memory card size	128 GB
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
Closest focusing distance	0.02 m
Camera shutter speed	0.0005 s
Display diagonal	3.5 \
Display resolution (numeric)	920000 pixels
Viewfinder type	Electronic
Viewfinder screen size	0.24 \
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Minimum illumination	4.5 lx
Product color	Black
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	60 fps
Video formats supported	MXF
Maximum video resolution	1920 x 1080 pixels
Maximum image resolution	- pixels
PCM digital audio	16-bit/48 kHz
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Battery voltage	7.4 V
Battery capacity	- mAh
Battery life (max)	- h
Video recording time	10.4 h
Operating temperature (T-T)	0 - 40 °C
Cables included	Component
Memory card included	CF
Video compression formats	MPEG2

Weight and Dimensions

Depth	250 mm
Width	121 mm
Height	148 mm
Weight	1290 g
