Canon XF105 User Manual

Audio Output
126
Audio Output
The camcorder can output audio from the HD/SD SDI terminal (b only), HDMI OUT terminal, AV terminal
or W (headphone) terminal. When audio is output from the AV terminal or W (headphone) terminal, you can
configure settings such as the output channel. When audio is output from the AV terminal, you can select the
output level.
b Embedded Audio
Embedded audio refers to the superimposing of the audio signal along with the video signal being output from
the HD/SD SDI terminal. If you set the [Video Setup] [SDI Output] setting to [HD] or [SD], the camcorder will
automatically embed audio.
Synchronizing the Video with the Audio being Monitored
When audio is output from the AV terminal or W (headphone) terminal,
you can choose to synchronize the audio signal with the video signal or
have the camcorder output the audio in real time. When the audio is
output in real time, there will be a slight delay. Regardless of the setting,
however, the audio and video signals recorded will be synchronized.
1 Open the [Monitor Delay] submenu.
[m Audio Setup] [Audio Output] [Monitor Delay]
2 Select the desired option and then press SET.
Options
Selecting the Audio Channel
You can select the audio channel that is output from the AV terminal or W
(headphone) terminal.
1 Open the [Channel] submenu.
[m Audio Setup] [Audio Output] [Channel]
2 Select the desired option and then press SET.
Operating modes:
Operating modes:
[Line Out]: Synchronizes the audio and video signals.
[Normal]: Allows you to monitor the audio in real time.
Operating modes:
[m Audio Setup]
[Audio Output]
[Monitor Delay]
[Normal]
[m Audio Setup]
[Audio Output]
[Channel]
[CH1/CH2]
COPY

Canon XF105 Specifications

General

Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/1.3 \
Effective megapixels (image)	2.07 MP
Filter size	58 mm
Digital zoom	- x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	4.25 - 42.5 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Minimum aperture number	1.8
Focal length (35mm film equivalent)	30.4 - 304 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	CF, SD
Maximum memory card size	128 GB
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
Closest focusing distance	0.02 m
Camera shutter speed	0.0005 s
Display diagonal	3.5 \
Display resolution (numeric)	920000 pixels
Viewfinder type	Electronic
Viewfinder screen size	0.24 \
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Minimum illumination	4.5 lx
Product color	Black
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	60 fps
Video formats supported	MXF
Maximum video resolution	1920 x 1080 pixels
Maximum image resolution	- pixels
PCM digital audio	16-bit/48 kHz
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Battery voltage	7.4 V
Battery capacity	- mAh
Battery life (max)	- h
Video recording time	10.4 h
Operating temperature (T-T)	0 - 40 °C
Cables included	Component
Memory card included	CF
Video compression formats	MPEG2

Weight and Dimensions

Depth	250 mm
Width	121 mm
Height	148 mm
Weight	1290 g
