Canon XF105 User Manual

79
Using Metadata
Using Metadata
The camcorder automatically adds metadata to clips while they are being recorded. Metadata consists of the
user-defined user memo* and recording data, such as shutter speed, exposure and focus settings. You can use
the supplied Canon XF Utility software to check and search for specific metadata.
* The user memo contains the clip title (up to 100 characters), camera operator (up to 100 characters), location (up to 100
characters) and clip description (up to 1,000 characters).
Setting a User Memo
Before you can add a user memo, you must first install the supplied
Canon XF Utility software (0 128). Next, create the user memo and
then save it to an SD card. Once you insert the SD card in the camcorder
and select the user memo, it will be added to clips you record.
For details on using the supplied software, refer to the instruction manual
that is installed with the Canon XF Utility software (0 134).
1Use Canon XF Utility to save a user memo to an SD card.
• For details, refer to Managing User Memo Profiles in the Canon XF Utility Instruction Manual.
2 Insert the SD card into the SD card slot of the camcorder.
3 Open the [User Memo] submenu.
[J Other Functions] [Set Metadata] [User Memo]
4 Select the file name of the desired user memo and then press SET.
•The f icon appears on the right side of the screen.
• Select [Off] to record clips without a user memo.
NOTES
• You must set the user memo before you start recording for it to be added to the clip. You cannot change the
user memo of a clip using the camcorder but you can do so with the Canon XF Utility software.
• You can also set a user-defined country code, organization code and user code for the metadata (0 150),
which is based on the UMID standard. However, the supplied Canon XF Utility software cannot display or
search for this information.
• After you set a user memo, do not remove the SD card while you are recording. If the SD card is removed, the
user memo will not be added to the clip.
Operating modes:
[J Other Functions]
[Set Metadata]
[User Memo]
COPY

Canon XF105 Specifications

General

Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/1.3 \
Effective megapixels (image)	2.07 MP
Filter size	58 mm
Digital zoom	- x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	4.25 - 42.5 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Minimum aperture number	1.8
Focal length (35mm film equivalent)	30.4 - 304 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	CF, SD
Maximum memory card size	128 GB
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
Closest focusing distance	0.02 m
Camera shutter speed	0.0005 s
Display diagonal	3.5 \
Display resolution (numeric)	920000 pixels
Viewfinder type	Electronic
Viewfinder screen size	0.24 \
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Minimum illumination	4.5 lx
Product color	Black
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	60 fps
Video formats supported	MXF
Maximum video resolution	1920 x 1080 pixels
Maximum image resolution	- pixels
PCM digital audio	16-bit/48 kHz
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Battery voltage	7.4 V
Battery capacity	- mAh
Battery life (max)	- h
Video recording time	10.4 h
Operating temperature (T-T)	0 - 40 °C
Cables included	Component
Memory card included	CF
Video compression formats	MPEG2

Weight and Dimensions

Depth	250 mm
Width	121 mm
Height	148 mm
Weight	1290 g
