Canon XF105 User Manual

125
Connecting to an External Monitor
Using the AV Terminal
When you output video from the AV terminal, the video signal is converted to an analog SD composite video
signal. In addition, the AV terminal also outputs audio. You can select the SD output method (0 122).
NOTES
• If necessary, you can superimpose the onscreen displays on the video displayed on the external monitor
(0 125).
• When you play back a clip on a monitor with a 4:3 aspect ratio, the monitor will switch automatically to
widescreen mode if it is compatible with the WSS system.
Superimposing Onscreen Displays to Appear on an
External Monitor
You can choose to superimpose onscreen displays on the video output
from the HD/SD SDI terminal (b only), HDMI OUT terminal, HD/SD
COMPONENT OUT terminal or AV terminal. Doing so will display the
onscreen displays on an external monitor. You must set this function
separately for HD and SD output. This setting will not affect your
recordings.
1 Open the [HD Onscreen Disp.] or [SD Onscreen Disp.] submenu.
[N Video Setup] [HD Onscreen Disp.] or [SD Onscreen Disp.]
2 Select [On] and then press SET.
• G appears on the right side of the screen (when [M LCD/VF Setup] [Custom Display 2] [Output
Display] is set to [On]).
NOTES
• Onscreen displays will not appear on an external monitor for SD output if [N Video Setup] [SD Output] is
set to [Side Crop].
[N Video Setup]
[HD Onscreen Disp.]
[SD Onscreen Disp.]
[Off]
COPY

Canon XF105 Specifications

General

Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/1.3 \
Effective megapixels (image)	2.07 MP
Filter size	58 mm
Digital zoom	- x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	4.25 - 42.5 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Minimum aperture number	1.8
Focal length (35mm film equivalent)	30.4 - 304 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	CF, SD
Maximum memory card size	128 GB
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
Closest focusing distance	0.02 m
Camera shutter speed	0.0005 s
Display diagonal	3.5 \
Display resolution (numeric)	920000 pixels
Viewfinder type	Electronic
Viewfinder screen size	0.24 \
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Minimum illumination	4.5 lx
Product color	Black
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	60 fps
Video formats supported	MXF
Maximum video resolution	1920 x 1080 pixels
Maximum image resolution	- pixels
PCM digital audio	16-bit/48 kHz
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Battery voltage	7.4 V
Battery capacity	- mAh
Battery life (max)	- h
Video recording time	10.4 h
Operating temperature (T-T)	0 - 40 °C
Cables included	Component
Memory card included	CF
Video compression formats	MPEG2

Weight and Dimensions

Depth	250 mm
Width	121 mm
Height	148 mm
Weight	1290 g
