Canon XF105 User Manual

93
Using the Focal Length Guide
Using the Focal Length Guide
The focal length guide aids you when using two camcorders for 3D recording. The guide appears as a numerical
value and has a range of 154 steps. You can set the guide to 0 at any point in the zoom range to help precisely
calibrate both camcorders.
1 Set up two camcorders and align their picture angle.
2 Open the [Focal Length Guide] submenu.
[l Camera Setup] [Zoom] [Focal Length Guide]
3 Select [Set To 0] and then press SET.
• The focal length guide appears on the left side of the screen as
[z ±0]. To turn off the indicator, select [Off] instead.
• You can obtain more accurate results by performing this step at full
telephoto.
• If both camcorders are set so that the same value is displayed during
zoom, the focal length for both camcorders will be maintained.
NOTES
• Although the focal length guide is an aid for 3D recording, make sure to check the picture angle visually while
recording.
Operating modes:
[l Camera Setup]
[Zoom]
[Focal Length Guide]
[Off]
COPY

Canon XF105 Specifications

General

Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/1.3 \
Effective megapixels (image)	2.07 MP
Filter size	58 mm
Digital zoom	- x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	4.25 - 42.5 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Minimum aperture number	1.8
Focal length (35mm film equivalent)	30.4 - 304 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	CF, SD
Maximum memory card size	128 GB
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
Closest focusing distance	0.02 m
Camera shutter speed	0.0005 s
Display diagonal	3.5 \
Display resolution (numeric)	920000 pixels
Viewfinder type	Electronic
Viewfinder screen size	0.24 \
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Minimum illumination	4.5 lx
Product color	Black
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	60 fps
Video formats supported	MXF
Maximum video resolution	1920 x 1080 pixels
Maximum image resolution	- pixels
PCM digital audio	16-bit/48 kHz
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Battery voltage	7.4 V
Battery capacity	- mAh
Battery life (max)	- h
Video recording time	10.4 h
Operating temperature (T-T)	0 - 40 °C
Cables included	Component
Memory card included	CF
Video compression formats	MPEG2

Weight and Dimensions

Depth	250 mm
Width	121 mm
Height	148 mm
Weight	1290 g
