k Logical Operators (AND, OR, NOT) [OPTN]-[LOGIC]
The logical operator menu provides a selection of logical operators.
• { And}/{Or}/{Not} ... {logical AND}/{logical OR}/{logical NOT}
• Be sure to specify Comp for Mode in the Setup screen.
Example What is the logical AND of A and B when A = 3 and B = 2?
A AND B = 1
Operation Display
3aav(A)w
2aal(B)w
av(A)K6(g)6(g)
4(LOGIC)1(And)al(B)w
1
Example What is the logical OR of A and B when A = 5 and B = 1?
A OR B = 1
Operation Display
5aav(A)w
1aal(B)w
av(A)K6(g)6(g)
4(LOGIC)2(Or)al(B)w
1
Example Negate A when A = 10.
NOT A = 0
Operation Display
10aav(A)w
K6(g)6(g)
4(LOGIC)3(Not)av(A)w
0
2-4-13
Function Calculations
