Cisco 4500M User Manual

14-17
Software Configuration Guide—Release 12.2(25)EW
OL-6696-01
Chapter 14 Understanding and Configuring STP
Configuring STP
To configure the spanning tree bridge priority of a VLAN, perform this task:
This example shows how to configure the bridge priority of VLAN 200 to 33,792:
Switch# configure terminal
Switch(config)# spanning-tree vlan 200 priority 33792
Switch(config)# end
Switch#
This example shows how to verify the configuration:
Switch# show spanning-tree vlan 200 bridge brief
Hello Max Fwd
Vlan Bridge ID Time Age Delay Protocol
---------------- -------------------- ---- ---- ----- --------
VLAN200 33792 0050.3e8d.64c8 2 20 15 ieee
Switch#
Configuring the Hello Time
Note Exercise care when configuring the hello time. In most cases, we recommend that you use the
spanning-tree vlan vlan_ID root primary and the spanning-tree vlan vlan_ID root secondary
commands to modify the hello time.
To configure the spanning tree hello time of a VLAN, perform this task:
This example shows how to configure the hello time for VLAN 200 to 7 seconds:
Switch# configure terminal
Switch(config)# spanning-tree vlan 200 hello-time 7
Switch(config)# end
Switch#
Command Purpose
Step 1
Switch(config)# [no] spanning-tree vlan vlan_ID
priority bridge_priority
Configures the bridge priority of a VLAN. The
bridge_priority value can be from 1 to 65,535.
You can use the no keyword to restore the defaults.
Step 2
Switch(config)# end
Exits configuration mode.
Step 3
Switch# show spanning-tree vlan vlan_ID bridge
[brief]
Verifies the configuration.
Command Purpose
Step 1
Switch(config)# [no] spanning-tree vlan vlan_ID
hello-time hello_time
Configures the hello time of a VLAN. The hello_time
value can be from 1 to 10 seconds.
You can use the no keyword to restore the defaults.
Step 2
Switch(config)# end
Exits configuration mode.
Step 3
Switch# show spanning-tree vlan vlan_ID bridge
[brief]
Verifies the configuration.
