Cisco 4500M User Manual

36-9
Software Configuration Guide—Release 12.2(25)EW
OL-6696-01
Chapter 36 Configuring Private VLANs
How to Configure PVLANs
This example shows how to configure interface FastEthernet 5/1 as a PVLAN host port and verify the
configuration:
Switch# configure terminal
Switch(config)# interface fastethernet 5/1
Switch(config-if)# switchport mode private-vlan host
Switch(config-if)# switchport private-vlan host-association 202 440
Switch(config-if)# end
Switch#show interfaces fastethernet 5/1 switchport
Name: Fa5/1
Switchport: Enabled
Administrative Mode: private-vlan host
Operational Mode: private-vlan host
Administrative Trunking Encapsulation: negotiate
Operational Trunking Encapsulation: native
Negotiation of Trunking: Off
Access Mode VLAN: 1 (default)
Trunking Native Mode VLAN: 1 (default)
Voice VLAN: none
Appliance trust: none
Administrative Private Vlan
Host Association: 202 (VLAN0202) 440 (VLAN0440)
Promiscuous Mapping: none
Trunk encapsulation : dot1q
Trunk vlans:
Operational private-vlan(s):
2 (VLAN0202) 3 (VLAN0440)
Trunking VLANs Enabled: ALL
Pruning VLANs Enabled: 2-1001
Capture Mode Disabled
Capture VLANs Allowed: ALL
Configuring a Layer 2 Interface as a PVLAN Trunk Port
To configure a Layer 2 interface as a PVLAN trunk port, perform this task:
Command Purpose
Step 1
Switch> enable
Enters privileged EXEC mode.
Step 2
Switch# configure terminal
Enters global configuration mode.
Step 3
Switch(config)# interface {fastethernet |
gigabitethernet | tengigabitethernet}
slot / port
Specifies the LAN port to configure.
Step 4
Switch(config-if)# switchport mode private-vlan
{host | promiscuous | trunk}
Configures a Layer 2 interface as a PVLAN trunk port for
multiple secondary VLANs.
