25-19
Software Configuration Guide—Release 12.2(25)EW
OL-6696-01
Chapter 25 Understanding and Configuring IP Multicast
Monitoring and Maintaining IP Multicast Routing
The following is sample output from the show ip mfib command.
IP Multicast Forwarding Information Base
Entry Flags: C - Directly Connected, S - Signal,
IC - Internal Copy
Interface Flags: A - Accept, F - Forward, S - Signal,
NP - Not platform switched
Packets: Fast/Partial/Slow Bytes: Fast/Partial/Slow:
(171.69.10.13, 224.0.1.40), flags (IC)
Packets: 2292/2292/0, Bytes: 518803/0/518803
Vlan7 (A)
Vlan100 (F NS)
Vlan105 (F NS)
(*, 224.0.1.60), flags ()
Packets: 2292/0/0, Bytes: 518803/0/0
Vlan7 (A NS)
(*, 224.0.1.75), flags ()
Vlan7 (A NS)
(10.34.2.92, 239.192.128.80), flags ()
Packets: 24579/100/0, 2113788/15000/0 bytes
Vlan7 (F NS)
Vlan100 (A)
(*, 239.193.100.70), flags ()
Packets: 1/0/0, 1500/0/0 bytes
Vlan7 (A)
..
The fast-switched packet count represents the number of packets that were switched in hardware on the
corresponding route.
The partially switched packet counter represents the number of times that a fast-switched packet was
also copied to the CPU for software processing or for forwarding to one or more non-platform switched
interfaces (such as a PimTunnel interface).
The slow-switched packet count represents the number of packets that were switched completely in
software on the corresponding route.
Displaying IP MFIB Fast Drop
To display fast-drop entries, perform this task:
The following is sample output from the show ip mfib fastdrop command.
Switch> show ip mfib fastdrop
MFIB fastdrop is enabled.
MFIB fast-dropped flows:
(10.0.0.1, 224.1.2.3, Vlan9 ) 00:01:32
(10.1.0.2, 224.1.2.3, Vlan9 ) 00:02:30
(1.2.3.4, 225.6.7.8, Vlan3) 00:01:50
The full (S,G) flow and the ingress interface on which incoming packets are dropped is shown. The
timestamp indicates the age of the entry.
Command Purpose
Switch# show ip mfib fastdrop
Displays all currently active fast-drop entries and indicates
whether fastdrop is enabled.
