Cisco ASR 1001-X User Manual

DescriptionDirectionSignalPin
Receive TIP (T1/E1)InputRX TIP2
Not used
—
N/C3, 4
Not used
—
TX Ring5
Not used
—
TX TIP6
——
N/C7,8
Cisco ASR 1002-X Router BITS Port Signals and Pinouts
Table 44: BITS RJ-45 Interface Pinouts for Cisco ASR 1002-X Router
DescriptionDirectionSignalPin
Receive RingInputRX Ring1
Receive TIP (T1/E1)InputRX TIP2
Not used
—
N/C3, 4
Transmit RingOutputTX Ring5
Transmit TIP (T1/E1)OutputTX TIP6
——
N/C7,8
Cisco ASR 1002-X Router BNC GPS Ports
Table 45: GPS Port Pinout
1PPS (input and output)10 Mhz (input and output)Signal Attribute
Input—Pulse shape
Output—Pulse shape
Input—Sine wave
Output—Square wave
Waveform
Input— > 2.4 volts TTL
compatible
Output— > 2.4 volts TTL
compatible
Input— > 1.7 volt p-p(+8 to +10
dBm)
Output— > 2.4 volts TTL
compatible
Amplitude
Cisco ASR 1001-X Router Hardware Installation Guide
132
Cisco ASR 1001-X Router Specifications
Cisco ASR 1002-X Router BITS Port Signals and Pinouts

Cisco ASR 1001-X Specifications

General

Product color	Gray
Rack capacity	1U
Rack mounting	Yes
Networking standards	-
Ethernet LAN (RJ-45) ports	6
Installed SFP modules quantity	2
Flash memory	1024 MB
Internal memory	8192 MB
Processor cores	4
AC input voltage	85 - 264 V
Power source type	AC
Power consumption (typical)	250 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Security algorithms	AES

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	10590 g
