The show platform software status control-processor command displays the average load, memory usage,
and CPU utilization levels at which the router is running. The output also specifies whether the levels of these
system health parameters are within defined thresholds.
The output does not display SIP-related information on a monolithic router.Note
The following is sample output from the show platform software status control-processor command:
show platform software status control-processor Command
Router# show platform software status control-processor
RP0: online, statistics updated 1 seconds ago
Load Average: healthy
1-Min: 0.00, status: healthy, under 8.00
5-Min: 0.03, status: healthy, under 8.00
15-Min: 0.07, status: healthy, under 10.00
Memory (kb): healthy
Total: 8092776
Used: 3491556 (43%)
Free: 4601220 (57%)
Committed: 3566404 (44%), status: healthy, under 95%
Per-core Statistics
CPU0: CPU Utilization (percentage of time spent)
User: 0.00, System: 0.00, Nice: 0.00, Idle:100.00
IRQ: 0.00, SIRQ: 0.00, IOwait: 0.00
CPU1: CPU Utilization (percentage of time spent)
User: 1.30, System: 0.40, Nice: 0.00, Idle: 98.30
IRQ: 0.00, SIRQ: 0.00, IOwait: 0.00
CPU2: CPU Utilization (percentage of time spent)
User: 0.49, System: 8.89, Nice: 0.00, Idle: 90.60
IRQ: 0.00, SIRQ: 0.00, IOwait: 0.00
CPU3: CPU Utilization (percentage of time spent)
User: 2.00, System: 0.40, Nice: 0.00, Idle: 97.60
IRQ: 0.00, SIRQ: 0.00, IOwait: 0.00
CPU4: CPU Utilization (percentage of time spent)
User: 0.00, System: 0.30, Nice: 0.00, Idle: 99.69
IRQ: 0.00, SIRQ: 0.00, IOwait: 0.00
CPU5: CPU Utilization (percentage of time spent)
User: 0.40, System: 0.10, Nice: 0.00, Idle: 99.50
IRQ: 0.00, SIRQ: 0.00, IOwait: 0.00
CPU6: CPU Utilization (percentage of time spent)
User: 0.40, System: 0.40, Nice: 0.00, Idle: 99.19
IRQ: 0.00, SIRQ: 0.00, IOwait: 0.00
CPU7: CPU Utilization (percentage of time spent)
User: 0.80, System: 1.30, Nice: 0.00, Idle: 97.90
IRQ: 0.00, SIRQ: 0.00, IOwait: 0.00
The show diag chassis eeprom detail command displays the configuration hardware information, including
DRAM and Static RAM (SRAM) on line cards.
The following is sample output from the show diag chassis eeprom detail command:
show diag chassis eeprom detail Command
Router#: show diag chassis eeprom detail
MIDPLANE EEPROM data:
EEPROM version : 4
Compatible Type : 0xFF
Controller Type : 2030
Hardware Revision : 1.0
PCB Part Number : 73-14409-07
Board Revision : A0
Deviation Number : 0-0
Fab Version : 07
PCB Serial Number : JAE1817044D
RMA Test History : 00
RMA Number : 0-0-0-0
Cisco ASR 1001-X Router Hardware Installation Guide
69
Cisco ASR 1001-X Router Power Up and Initial Configuration
Reporting Functions

Cisco ASR 1001-X Specifications

General

Product color	Gray
Rack capacity	1U
Rack mounting	Yes
Networking standards	-
Ethernet LAN (RJ-45) ports	6
Installed SFP modules quantity	2
Flash memory	1024 MB
Internal memory	8192 MB
Processor cores	4
AC input voltage	85 - 264 V
Power source type	AC
Power consumption (typical)	250 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Security algorithms	AES

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	10590 g
