12-6
Cisco Wireless LAN Controller Configuration Guide
OL-9141-03
Chapter 12 Configuring Hybrid REAPWireless Device Access
Configuring Hybrid REAP
switchport mode trunk
spanning-tree portfast
!
interface Vlan100
ip address 10.10.100.1 255.255.255.0
ip helper-address 10.10.100.1
!
interface Vlan101
ip address 10.10.101.1 255.255.255.0
ip helper-address 10.10.101.1
end
Configuring the Controller for Hybrid REAP
This section provides instructions for configuring the controller for hybrid REAP using either the GUI
or the CLI.
Using the GUI to Configure the Controller for Hybrid REAP
The controller configuration for hybrid REAP consists of creating centrally switched and locally
switched WLANs. Follow the steps in this section to use the GUI to configure the controller for these
WLANs. This procedure uses these three WLANs as examples:
Note See the “Using the CLI to Configure the Controller for Hybrid REAP” section on page 12-12 if you
would prefer to configure the controller for hybrid REAP using the CLI.
Step 1 Follow these steps to create a centrally switched WLAN. In our example, this is the first WLAN
(employee).
a. Click WLANs to access the WLANs page.
b. Click Next to access the WLANs > New page (see Figure 12-2).
WLAN Security Switching Interface Mapping (VLAN)
employee WPA1+WPA2 Central management (centrally switched
VLAN)
employee-local WPA1+WPA2 (PSK) Local 101 (locally switched VLAN)
guest-central Web authentication Central management (centrally switched
VLAN)
