Cisco Wireless LAN Controller Configuration Guide

Ol-9141-03

Appendix A Safety Considerations and Translated Safety Warnings

Class 1 Laser Product Warning

Note The 1000BASE-SX and 1000BASE-LX SFP modules contain Class 1 Lasers (Laser Klasse 1) according

to EN 60825-1+A1+A2.

Warning

Class 1 laser product.

Statement 1008

Waarschuwing

Klasse-1 laser produkt.

Varoitus

Luokan 1 lasertuote.

Attention

Produit laser de classe 1.

Warnung

Laserprodukt der Klasse 1.

Avvertenza

Prodotto laser di Classe 1.

Advarsel

Laserprodukt av klasse 1.

Aviso

Produto laser de classe 1.

¡Advertencia!

Producto láser Clase I.

Varning!

Laserprodukt av klass 1.
