112
4. Disassemble PT
O h
ydraulic clutch assy
.
(1) Case
(9) Brake disk
(2) Piston
(10) Seal ring set
(3)
Seal
ring
(11) Gear set 40T
(4) Disk assy
(12) Seal ring
(5) Ring set
(13) Ring
(6) Spring
(14) Back plate
(7) W
asher
(15) Belleville spring
(8) Return plate
(16) Ring
(3) 4WD SHAFT DISASSEMBLING.
112
114
