7-7. CHECK AND MAINTENANCE
(1) BACKLASH
1. Check the backlash at differential case assy ]
and side clearance. In case that the values are
out of the following standard, adjust them.
Item
Standard (in.)
Backlash at differential case assy 0.004~0.015
Side clearance at differential case assy 0~0.004
Backlash between diff. ring gear and pinion shaft 0.004~0.012
2. Check the backlash between diff. shaft and
final gear 59T. In case that the backlash is out
of following standard, replace them.
Item
Standard (in.) Service limit(in.)
Backlash between final 0.004~0.012 0.02
gear and diff.shaft
(2) BRAKE DISK
1. Check the worn out of brake disks. In case
that the measurement value is out of standard,
replace the disks.
Item Standard (in.) Service limit (in.)
Thickness 0.134 0.126
of brake disk
(3) BRAKE PEDAL
1. Check the clearance between inner diameter
of bushing on brake pedal R.H. and outer
diameter of brake shaft. In case that the
clearance is out of service limit, replace the
bushing.
Item Standard(in.) Service limit(in.)
Clearance between
inner diameter of 0.0016~ 0.197
bushing and outer 0.0047
diameter of shaft
