4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual
19
4 Configuration
The features and functions of the D-Link DGS-1210/ME Metro Ethernet Switch can be configured through
the web-based management interface.
Web-based Management
After press the OK button in Logon Dialog Box, you will see the screen below:
Figure 4.1 – Web-based Management
The three main areas are the Tool Bar on top, the Function Tree on the left, and the Main Configuration
Screen.
The Tool Bar provides a quick and convenient way for accessing essential functions such as firmware
upgrades and basic settings.
Clicking on a section or subsection in the function tree will display all the settings of that section in the main
configuration screen. The main configuration screen will show the current status of your Switch by clicking
the model name on top of the function tree.
In the upper-right corner of the screen the username and current IP address will be displayed.
Under the username is the Logout button. Click this to end this session.
NOTE:
If you close the web browser without
clicking the Logout button first, then it will be seen
as an abnormal exit and the login session will still
be occupied.
Finally, by clicking on the D-Link logo at the upper-left corner of the screen you will be redirected to the local
D-Link website.
