D-Link xStack DGS-3620 Series User Manual

xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide
1042
Queue Bandwidth Control Table On Port: 1
Queue Min Rate(Kbit/sec) Max Rate(Kbit/sec)
0 No Limit No Limit
1 No Limit No Limit
2 64 1024
3 64 No Limit
4 No Limit No Limit
5 No Limit No Limit
6 No Limit No Limit
7 No Limit No Limit
DGS-3620-28PC:admin#
91-5 config scheduling
Description
This command is used to configure the traffic scheduling mechanism for each CoS queue.
Format
config scheduling {ports [<portlist> | all]} <class_id 0-7> [strict | weight <value 1-127>]
Parameters
ports - (Optional) Specifies the range of ports to be configured.
<portlist> - Enter the list of ports here.
all - Specifies that all the ports will be used.
<class_id 0-7> - Specifies the 8 hardware priority queues that the config scheduling command
will apply to. The eight hardware priority queues are identified by a number from 0 to 7 with
the 0 queue being the lowest priority.
strict - Specifies that the queue will operate in strict mode.
weight - Specifies the weight value for weighted round robin. The queue will operate in WRR
mode if the port mode is WRR. It will operate in strict mode if the port mode is strict.
<value 1-127> - Enter the weight value here. This value must be between 1 and 127.
Restrictions
Only Administrators, Operators and Power-Users can issue this command.
Example
To configure the traffic scheduling on CoS queue 0 with a maximum packet value of 10:
DGS-3620-28PC:admin#config scheduling 0 weight 10
Command: config scheduling 0 weight 10
Success.
DGS-3620-28PC:admin#
