xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide
234
DGS-3620-28PC:admin#create cfm md op_domain level 2
Command: create cfm md op_domain level 2
Success.
15-2 config cfm md
Description
This command is used to configure the parameters of a maintenance domain. The creation of
MIPs on an MA is useful to trace the link, MIP by MIP. It also allows the user to perform a loopback
from an MEP to an MIP.
Format
config cfm md [<string 22> | md_index <uint 1-4294967295>] {mip [none | auto | explicit] |
sender_id [none | chassis | manage | chassis_manage]}(1)
Parameters
<string 22> - Enter the maintenance domain name used here. This name can be up to 22
characters long.
md_index - Specifies the maintenance domain index used.
<uint 1-4294967295> - Enter the maintenace domain index value used here. This value must
be between 1 and 4294967295.
mip - (Optional) This is the control creations of MIPs.
none - Do not create MIPs. This is the default value.
auto - MIPs can always be created on any port in this MD if the port is not configured with an
MEP of this MD.
explicit - MIPs can only be created on any port in this MD if the next existing lower level has
an MEP configured on that port, and that port is not configured with an MEP of this MD.
sender_id - (Optional) This is the control transmission of the sender ID TLV.
none - Do not transmit the sender ID TLV. This is the default value.
chassis - Transmit the sender ID TLV with the chassis ID information.
manage - Transmit the sender ID TLV with the managed address information.
chassis_manage - Transmit the sender ID TLV with chassis ID information and manage
Restrictions
Only Administrators, Operators and Power-Users can issue this command. (EI Mode Only
Command)
Example
To configure the maintenance domain called “op_domain” and specify the explicit option for
creating MIPs:
DGS-3620-28PC:admin#config cfm md op_domain mip explicit
Command: config cfm md op_domain mip explicit
