Recommendations
gG type fuses.
Moeller type circuit breakers. For other circuit breaker types, ensure that the energy into the drive is equal to or lower than the
energy provided by Moeller types.
For further information, see Application Note Fuses and Circuit Breakers.
The recommended fuses in and are suitable for use on a circuit capable of 100000 A
rms
(symmetrical), depending on the drive volt-
age rating. With the proper fusing, the drive short circuit current rating (SCCR) is 10000 A
rms
.
10.6.2 CE Compliance
Table 68: 200–240 V, Enclosure Sizes A, B, and C
Enclosure
Power [kW (hp)]
Recommended
fuse size
Recommended
maximum fuse
Recommended circuit
breaker Moeller
Maximum trip
level [A]
A2
0.25–1.5 (0.34–2.0)
gG-10
gG-25
PKZM0-25
25
2.2 (3.0)
gG-16
A3
3.0 (4.0)
gG-16
gG-32
PKZM0-25
25
3.7 (5.0)
gG-20
A4
0.25–1.5 (0.34–2.0)
gG-10
gG-32
PKZM0-25
25
2.2 (3.0)
gG-16
A5
0.25–1.5 (0.34–2.0)
gG-10
gG-32
PKZM0-25
25
2.2–3.0 (3.0–4.0)
gG-16
3.7 (5.0)
gG-20
B1
5.5 (7.5)
gG-25
gG-80
PKZM4-63
63
7.5–11 (10–15)
gG-32
B2
15 (20)
gG-50
gG-100
NZMB1-A100
100
B3
5.5–7.5 (7.5–10)
gG-25
gG-63
PKZM4-50
50
11 (15)
gG-32
B4
15 (20)
gG-50
gG-125
NZMB1-A100
100
18 (24)
gG-63
C1
18 (24)
gG-63
gG-160
NZMB2-A200
160
22 (30)
gG-80
30 (40)
gG-100
aR-160
C2
37 (50)
aR-160
aR-200
NZMB2-A250
250
45 (60)
aR-200
aR-250
C3
22 (30)
gG-80
gG-150
NZMB2-A200
150
30 (40)
aR-125
aR-160
C4
37 (50)
aR-160
aR-200
NZMB2-A250
250
45 (60)
aR-200
aR-250
AJ300847815559en-000101 / 130R0337126 | Danfoss A/S © 2020.09
Electrical Installation
Considerations
VLT® AQUA Drive FC 202
Design Guide
