Danfoss VLT AQUA FC 202 Design Guide

•
•
•
•
•
•
•
•
•
•
•
•
•
Accessory bag type
Description
Ordering number
Accessory bag C1
Accessory bag, enclosure size C1
130B0046
Accessory bag C2
Accessory bag, enclosure size C2
130B0047
Accessory bag C3
Accessory bag, enclosure size C3
130B0981
Accessory bag C4
Accessory bag, enclosure type C4, 55 kW
130B0982
Accessory bag C4
Accessory bag, enclosure type C4, 75 kW
130B0983
Example of an accessory bag content (130B0046)
Loadsahre warning label
Eye bolt M10
2 relay plugs
3-pole spring cage connector
6-pole spring cage connector
Label
Terminal strap
3 cable clamps
4 metric screws M4 and M6
1 thread froming screw
3 cable bearers
13.2.11 Ordering of Harmonic Filters
Harmonic lters are used to reduce mains harmonics. Danfoss oers 2 dierent harmonic lters:
VLT® Advanced Harmonic Filter AHF 005 with 5% current distortion.
VLT® Advanced Harmonic Filter AHF 010 with 10% current distortion.
The lters are cooled by natural convection or with built-in fans. Secure sucient airow through the lter during installation to
prevent overheating the lter. An airow of minimum 2 m/s is required through the lter.
13.2.11.1 Order Numbers for Harmonic Filters, 380–415 V, 50 Hz
Table 144: Ordering Numbers for Harmonic Filters, 380–415 V, 50 Hz
Drive values
AHF values
Power rat-
ing [kW]
(1)
Input cur-
rent 380–
440 V [A]
Current rat-
ing [A]
Ordering numbers
(2)
Enclosure type
AHF 005 IP20
AHF 010 IP20
AHF 005 IP20
AHF 010 IP20
0.37
1.2
10
130B1229
130B1027
X1-V3 IP20 if
X1-V3 IP20 if
0.55
1.6
0.75
2.2
1.1
2.7
1.5
3.7
2.2
5.0
3.0
6.5
AJ300847815559en-000101 / 130R0337198 | Danfoss A/S © 2020.09
How to Order a Drive
VLT® AQUA Drive FC 202
Design Guide
