Danfoss VLT AQUA FC 202 Design Guide

13 How to Order a Drive
13.1 Drive Congurator
F
C
-
P
T
e30bb836.10
X S A B CX X X X
1
2
3
4 5
6
7
8 9 10
11
12 13 14 15
16 17
18
19 20 302221 23 272524 26 28 29 31 373635343332 38 39
X D
Illustration 96: Type Code Example
Congure the right drive for the right application from the internet-based Drive Congurator and generate the type code string. The
Drive Congurator automatically generates an 8-digit sales number to be delivered to the local sales oce. Furthermore, it is possi-
ble to establish a project list with several products and send it to a Danfoss sales representative.
The Drive Congurator can be found on the global website: www.danfoss.com/drives.
13.1.1 Type Code
An example of the type code is:
FC-202PK75T4E20H1BGCXXXSXXXXA0BXCXXXXD0
The meaning of the characters in the string is described in Table 122 and Table 123. In the example above, a PROFIBUS V1 and a 24 V
back-up option is built in.
Table 122: Ordering Type Code, Enclosure Sizes A, B, and C
Description
Position
Possible options
Product group
1–2
FC
Drive series
4–6
202
Power rating
8–10
0.25–90 kW (0.34–110 hp)
Phases
11
S: Single phase
T: Three phases
Mains voltage
12
S2: 200–240 V
T2: 200–240 V
T4: 380–480 V
T6: 525–600 V
T7: 525–690 V
Enclosure
13–15
E20: IP20
E55: IP55/NEMA Type 12
P20: IP20 (with backplate)
P21: IP21/NEMA Type 12 (with backplate)
P55: IP55/NEMA Type 12 (with backplate)
Z20: IP21
E66: IP66
RFI lter
16–17
Hx: No EMC lters built in the drive (600 V units only)
H1: Integrated EMC lter. Full EN 55011 Class A1/B and EN/IEC 61800-3 Category 1/2
H2: No extra EMC lter. Full EN 55011 Class A2 and EN/IEC 61800-3 Category 3
AJ300847815559en-000101 / 130R0337178 | Danfoss A/S © 2020.09
How to Order a Drive
VLT® AQUA Drive FC 202
Design Guide
