Danfoss VLT AQUA FC 202 Design Guide

Drive values
AHF values
1000
1675
1720
2 x 130B1260 + 2 x
130B1261
2 x 130B1217 + 2 x
130B1228
1
The power ratings in the selection table are the actual operating power and not necessarily the type code power rating. Changing operating condi-
tions between HO and NO changes the actual operating conditions and the lter selection must reect actual operating conditions.
2
The fan control system allows extended input voltage range as 200–415 V. The AHFs for 380–415 V/50 Hz mains operation can be operated with
200–240 V mains supply.
3
Filters are used as paralleling for 355 kW drive.
13.2.11.2 Order Numbers for Harmonic Filters, 380–415 V, 60 Hz
Table 145: Ordering Numbers for Harmonic Filters, 380–415 V, 60 Hz
Drive values
AHF values
Power rat-
ing [kW]
(1)
Input current
380-440V [A]
Current
rating [A]
Ordering numbers
(2)
Enclosure type
AHF 005 IP20
AHF 010 IP20
AHF 005 IP20
AHF 010 IP20
0.37
1.2
10
130B2857
130B2262
X1-V3 IP20 if
X1-V3 IP20 if
0.55
1.6
0.75
2.2
1.1
2.7
1.5
3.7
2.2
5.0
3.0
6.5
4.0
9.0
5.5
11.7
14
130B2858
130B2265
X1-V3 IP20 ef
X1-V3 IP20 ef
7.5
14.4
11
22
22
130B2859
130B2268
X2-V3 IP20 ef
X2-V3 IP20 if
15
29
29
130B2860
130B2294
X2-V3 IP20 ef
X2-V3 IP20 if
18.5
34
34
130B2861
130B2297
X3-V3 IP20 if
X3-V3 IP20 if
22
40
40
130B2862
130B2303
X3-V3 IP20 if
X3-V3 IP20 if
30
55
55
130B2863
130B2445
X3-V3 IP20 if
X3-V3 IP20 if
37
66
66
130B2864
130B2459
X4-V3 IP20 if
X4-V3 IP20 if
45
82
82
130B2865
130B2488
X4-V3 IP20 ef
X4-V3 IP20 ef
55
96
96
130B2866
130B2489
X5-V3 IP20 ef
X5-V3 IP20 ef
75
133
133
130B2867
130B2498
X5-V3 IP20 ef
X5-V3 IP20 ef
90
171
171
130B2868
130B2499
X6-V3 IP20 ef
X6-V3 IP20 if
110
204
204
130B2869
130B2500
X6-V3 IP20 ef
X6-V3 IP20 if
132
251
251
130B2870
130B2700
X7-V3 IP20 if
X7-V3 IP20 if
