Danfoss VLT AQUA FC 202 Design Guide

FC 202
Vertical braking 40% duty cycle
T2
3.0
(4.0)
45
53.7
48
0.960
175U3303
175R3406
175U3405
–
1.5 (16)
4.2
T2
3.7
(5.0)
31.5
39.9
35
1.130
175U3304
175U3408
175U3407
–
1.5 (16)
5.4
T2
5.5
(7.5)
22.5
28.7
27
1.400
175U3305
175U3410
175U3409
–
1.5 (16)
6.8
T2
7.5
(10)
17.7
20.8
18
2.200
175U3306
175U3412
175U3411
–
1.5 (16)
10.4
T2
11 (15)
12.6
14
13
3.200
175U3307
175U3414
175U3413
–
2.5 (14)
14.7
T2
15 (20)
8.7
10.2
9.0
5.500
–
175U3176
175U3177
–
4 (12)
23
T2
18.5
(25)
5.3
8.2
5.7
6.000
–
–
–
175U3233
10 (8)
33
T2
22 (30)
5.1
6.9
5.7
8.000
–
–
–
175U3234
10 (8)
38
T2
30 (40)
3.2
5.0
3.5
9.000
–
–
–
175U3235
16 (6)
51
T2
37 (50)
3.0
4.1
3.5
14.000
–
–
–
175U3224
25 (4)
63
T2
45 (60)
2.4
3.3
2.8
17.000
175U3227
35 (2)
78
13.2.9.3 Order Numbers for Brake Resistors, T2, Flat-pack for Horizontal Conveyors
Table 135: Flat-pack IP65 Brake Resistors for Horizontal Conveyors, FC 202 T2, 200–240 V
Flat-pack IP65 for horizontal conveyors
FC 202 T2
P
m
[kW]
R
min
[Ω]
R
br,nom
[Ω]
R
rec
per item [Ω/W]
Duty cycle [%]
Ordering number
PK25
0.25 (0.34)
380
691.3
430/100
40
175U1002
PK37
0.37 (0.50)
380
466.7
430/100
27
175U1002
PK55
0.55 (0.75)
275
313.7
330/100
18
175U1003
PK55
0.55 (0.75)
275
313.7
310/200
36
175U0984
PK75
0.75 (1.0)
188
230
220/100
13
175U1004
PK75
0.75 (1.0)
188
230
210/200
26
175U0987
P1K1
1.1 (1.5)
130
152.9
150/100
9
175U1005
P1K1
1.1 (1.5)
130
152.9
150/200
18
175U0989
P1K5
1.5 (2.0)
81
110.5
100/100
7
175U1006
P1K5
1.5 (2.0)
81
110.5
100/200
14
175U0991
P2K2
2.2 (3.)
58.5
74.1
72/200
9
175U0992
P3K0
3.0 (4.0)
45
53.7
50/200
7
175U0993
P3K7
3.7 (5.0)
31.5
39.9
35/200
6
175U0994
P3K7
3.7 (5.0)
31.5
39.9
72/200
11
2 x 175U0992
AJ300847815559en-000101 / 130R0337 | 187Danfoss A/S © 2020.09
How to Order a Drive
VLT® AQUA Drive FC 202
Design Guide
