Danfoss VLT AQUA FC 202 Design Guide

Speed accuracy (open loop)
30–4000 RPM: Error ±8 RPM
All control characteristics are based on a 4-pole asynchroneous motor.
8.7 Connection Tightening Torques
Table 42: Terminal Tightening Torques
Enclosure
size
Mains [Nm (in-lb)]
Motor [Nm (in-lb)]
DC Connection
[Nm (in-lb)]
Brake [Nm (in-
lb)]
Ground [Nm (in-
lb)]
Relay [Nm (in-
lb)]
A2
1.8 (16)
1.8 (16)
1.8 (16)
1.8 (16)
3 (27)
0.6 (5)
A3
1.8 (16)
1.8 (16)
1.8 (16)
1.8 (16)
3 (27)
0.6 (5)
A4
1.8 (16)
1.8 (16)
1.8 (16)
1.8 (16)
3 (27)
0.6 (5)
A5
1.8 (16)
1.8 (16)
1.8 (16)
1.8 (16)
3 (27)
0.6 (5)
B1
1.8 (16)
1.8 (16)
1.5 (13)
1.5 (13)
3 (27)
0.6 (5)
B2
4.5 (40)
4.5 (40)
3.7 (33)
3.7 (33)
3 (27)
0.6 (5)
B3
1.8 (16)
1.8 (16)
1.8 (16)
1.8 (16)
3 (27)
0.6 (5)
B4
4.5 (40)
4.5 (40)
4.5 (40)
4.5 (40)
3 (27)
0.6 (5)
C1
10 (89)
10 (89)
10 (89)
10 (89)
3 (27)
0.6 (5)
C2
14/24 (124/221)
(1)
14/24 (124/221)
(1)
14 (124)
14 (124)
3 (27)
0.6 (5)
C3
10 (89)
10 (89)
10 (89)
10 (89)
3 (27)
0.6 (5)
C4
14/24 (124/221)
(1)
14/24 (124/221)
(1)
14 (124)
14 (124)
3 (27)
0.6 (5)
1
For dierent cable dimensions x/y, where x≤95 mm
2
(3 AWG) and y≥95 mm
2
(3 AWG).
8.8 Power Ratings, Weight, and Dimensions
Table 43: Power Ratings, Weight, and Dimensions, Enclosure Size A
Enclosure size
A2
A3
A4
A5
3x525–690 V
T7
–
1.1–7.5 (1–10)
–
–
3x525–600 V
T6
–
0.75–7.5 (1.0–10)
–
0.75–7.5 (1.0–
10)
3x380–480 V
T4
0.37–4.0 (0.5–5.0)
5.5–7.5 (7.5–10)
0.37–4.0 (0.5–
5)
0.37–7.5 (0.5–
10)
1x380–480 V
S4
–
–
–
–
3x200–240 V
T2
0.25–2.2 (0.34–3.0)
3.0–3.7 (4.0–5.0)
0.25–2.2 (0.34–
3.0)
0.25–3.7 (0.34–
5)
1x200–240 V
S2
–
1.1 (1.5)
1.1 (1.5)
IPNEMA
20Chassis
21Type 1
20Chassis
21Type 1
55/66Type
12/4X
55/66Type
12/4X
Height [mm (in)]
Height of backplate
A
(1)
268 (10.6)
375 (14.8)
268 (10.6)
375 (14.8)
390 (15.4)
420 (16.5)
AJ300847815559en-000101 / 130R0337 | 95Danfoss A/S © 2020.09
Specications
VLT® AQUA Drive FC 202
Design Guide
