Two wires are required.
2
Variant not available in IP21.
3
Applies for dimensioning of drive cooling. If the switching frequency is higher than the default setting, the power losses may increase. LCP and
typical control card power consumptions are included. For more detailed eciency values and part load losses according IEC/EN 61800-9-2 refer to
mydrive ecosmart on
www. danfoss.com. For eciency class see 8.4.1 Environment.
4
Eciency measured at nominal current. For more detailed eciency values and part load losses according IEC/EN 61800-9-2 refer to mydrive ecos-
mart on www. danfoss.com. For eciency class see 8.4.1 Environment.
5
Measured using 5 m (16 ft) shielded motor cables at rated load and rated frequency. For more detailed eciency values and part load losses ac-
cording IEC/EN 61800-9-2 refer to mydrive ecosmart on
www. danfoss.com. For eciency class see 8.4.1 Environment.
8.1.2 Mains Supply 3x200–240 V AC
Table 26: Mains Supply 3x200–240 V AC, PK25–PK75
Typical shaft output [kW]
Typical shaft output at 208 V [hp]
Protection rating IP20/Chassis
(2)
Protection rating IP21/Type 1
Protection rating IP55/Type 12
Protection rating IP66/NEMA 4X
Continuous (3x200–240 V) [A]
Intermittent (3x200–240 V) [A]
Continuous kVA at 208 V [kVA]
Continuous (3x200–240 V) [A]
Intermittent (3x200–240 V) [A]
Maximum cable cross-section
(3)
for mains, motor, brake, and load sharing [mm
2
(AWG)]
4, 4, 4 (12, 12, 12)
(minimum 0.2 (24))
Maximum cable cross-section
(3)
for mains disconnect [mm
2
(AWG)]
Estimated power loss
(4)
at rated maximum load [W]
(5)
