Datalogic PowerScan PD9530 User Manual

Enter/Exit Programming Mode
Product Reference Guide 229
Bluetooth HID Variable PIN Code
Specifies the selection available for Static or Variable Pin Code, when Blue-
tooth HID profile is configured.
Some Bluetooth drivers on the Host (such as WIDCOMM and BlueSoleil 8)
require a Variable PIN Code. When attempting connection, the application
presents a window that includes a PIN Code which is to be input using the
PowerScan BT9500. Scan the bar code "Variable PIN Code" below, then use
the host computer’s Bluetooth manager to “Discover new devices” and select
"Datalogic Scanner." Use a text editor to see incoming data on the port des-
ignated by the computer's Bluetooth manager.
If you receive an error message, it may be necessary to disable
security on the device.
When you hear the beep and see the Green LED blinking indicating the
reader is waiting for an alphanumeric entry, enter the required variable PIN
Code by scanning the corresponding bar codes in Appendix D, Keypad for
alphanumeric entry. Finish by scanning the Exit HID Variable PIN Code label.
$CBTHP00
Set Static Pin Code
DEFAULT
DEFAULT
$CBTHP01
Set Variable Pin code
~
CANCEL
Make a mistake? Scan the CANCEL bar code to abort
and not save the entry string. You can then start again
at the beginning.
Exit HID Variable PIN Code

Datalogic PowerScan PD9530 Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Tilt reading angle	0 - 360 °
Pitch reading angle	-40 - 40 °
Linear (1D) barcodes supported	-
Standard interfaces	RS-232, USB, Keyboard wedge
Connectivity technology	Wired
Product color	Black, Yellow
International Protection (IP) code	IP65
Input voltage	5 V
Power consumption	350 mA
Power source type	DC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Cables included	No

Weight and Dimensions

Depth	110 mm
Width	74 mm
Height	212 mm
Weight	330 g
