Datalogic PowerScan PD9530 User Manual

Enter/Exit Programming Mode
268 PowerScan™ PD9530/PBT9500/PM9500
Set F3 Label
This item allows the user to change the default mnemonic label associated
to each individual function key. This is done by programming a short acro-
nym 4-character string to be shown in the bottom of the display. The pur-
pose of the label is to serve as an indication of the programmed function of
th
e Fu
nction Key below it.
$CPWSD
Set F3 label
To configure this feature, scan the ENTER/EXIT PRO-
GRAMMING MODE bar code above, then the bar code at
left followed
by 8 digits from the
Appendix D, Key-
pad
. The digits must be the hexadecimal ASCII represen-
tation of the desired characters.
End by scanning the ENTER/EXIT bar code again.
Set F4 Label
This item allows the user to change the default mnemonic label associated
to each individual function key. This is done by programming a short acro-
nym 4-character string to be shown in the bottom of the display. The pur-
pose of the label is to serve as an indication of the programmed function of
th
e Fu
nction Key below it.
$CPWSE
Set F4 label
To configure this feature, scan the ENTER/EXIT PRO-
GRAMMING MODE bar code above, then the bar code at
left followed
by 8 digits from the
Appendix D, Key-
pad
. The digits must be the hexadecimal ASCII represen-
tation of the desired characters.
End by scanning the ENTER/EXIT bar code again.

Datalogic PowerScan PD9530 Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Tilt reading angle	0 - 360 °
Pitch reading angle	-40 - 40 °
Linear (1D) barcodes supported	-
Standard interfaces	RS-232, USB, Keyboard wedge
Connectivity technology	Wired
Product color	Black, Yellow
International Protection (IP) code	IP65
Input voltage	5 V
Power consumption	350 mA
Power source type	DC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Cables included	No

Weight and Dimensions

Depth	110 mm
Width	74 mm
Height	212 mm
Weight	330 g
