Enter/Exit Programming Mode
242 PowerScan™ PD9530/PBT9500/PM9500
Base Address Stamping
Enables/disables the ability of base address information to be transmitted to
the host and, if so, at what position with respect to the label data. See
page 304 in “References” for detailed information and examples for setting
this feature.
DEFAULT
$CCNAS00(CR)
Base Address Transmission = Do Not Include
$CCNAS01(CR)
Base Address Transmission = Prefix
Base Address Delimiter Character
This option specifies the delimiter character to be placed between the label
data and base address when address stamping is enabled.
$CCNAD
Set Base Address Delimiter Character
To configure this feature, scan the ENTER/EXIT PRO-
GRAMMING MODE bar code above, then the bar code at
left followed by two digits from the Alphanumeric
char
acters in
Appendix D, Keypad representing
your desired character. End by scanning the ENTER/
EXIT bar code aga
in.
Make a mistake? Scan the CANCEL bar code to abort
and not
save the entry string. You can then start again
at the beginning.
~
CANCEL
DEFAULT
00 = No Delimiter Character
This feature only applies if "Base Address Stamping" on page 242
is enabled.

Datalogic PowerScan PD9530 Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Tilt reading angle	0 - 360 °
Pitch reading angle	-40 - 40 °
Linear (1D) barcodes supported	-
Standard interfaces	RS-232, USB, Keyboard wedge
Connectivity technology	Wired
Product color	Black, Yellow
International Protection (IP) code	IP65
Input voltage	5 V
Power consumption	350 mA
Power source type	DC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Cables included	No

Weight and Dimensions

Depth	110 mm
Width	74 mm
Height	212 mm
Weight	330 g
