Enter/Exit Programming Mode
238 PowerScan™ PD9530/PBT9500/PM9500
Changing System Speed
1. Link the PM9500 with a BC9xxx Base.
2. With the PM9500, read a “Compatibl
e Mode/Normal Mode Speed” pro-
gramming label on page 240 to set “Low, Medium, or High Speed”.
3. Place the PM9500 into the BC9xxx.
Th
e Reader and Base will now be linked at the new programmed speed.
This feature can also be programmed using Datalogic Aladdin.
1. On the BC9xxx Base, change the Compat
ible mode parameter to low,
intermediate, or high speed through Aladdin.
2. Place an unlinked PM9500 onto the BC9xxx base.
The Reader and base will link at the new programmed speed.
Frequency Agility
In exceptionally noisy environments or in case of a high concentration of
radio devices, Star system performance may be improved by configuring
Frequency Agility. Frequency Agility parameters change the way the radio
frequencies are used in a Star communication system.
As when changing the System Speed, use the following procedure:
1. Link the PM9500 with a BC9xxx Base.
2. With the PM9500, read one of the “Frequency Agility” programming
labe
ls below.
3. Place the PM9500 into the BC9xxx.
R
eader and Base will then be linked and the new frequencies handling will be
oper
ational.
DEFAULT
$CSTFA00
Use default fixed channel
$CSTFA80
Enable frequency hopping
The channel is changed automatically

Datalogic PowerScan PD9530 Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Tilt reading angle	0 - 360 °
Pitch reading angle	-40 - 40 °
Linear (1D) barcodes supported	-
Standard interfaces	RS-232, USB, Keyboard wedge
Connectivity technology	Wired
Product color	Black, Yellow
International Protection (IP) code	IP65
Input voltage	5 V
Power consumption	350 mA
Power source type	DC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Cables included	No

Weight and Dimensions

Depth	110 mm
Width	74 mm
Height	212 mm
Weight	330 g
