Customizing Configuration Settings
Product Reference Guide 17
Customizing Configuration Settings
Configure Interface Settings
If after scanning the interface bar code from the previous table, your instal-
lation requires you to select options to further customize your reader, turn
to
the appropriate section for your interface type in "Configuration Parame-
ters" starting on page 21.
Global Interface Features
See "Global Interface Features" on page 23 for settings configurable by all
interface types.
Configuring Other Features
If your installation requires different programming than the standard factory
default settings, the following sections of this manual allow configuration of
non-interface-specific settings you might require. Go to Configuration
Using Bar Codes, starting on page 21 for a complete list of available options.
Software Version Transmission
The software version of the device can be transmitted over the RS-232 and
Keyboard interfaces by scanning the following label.
Transmit Software Version
RevA\r
Self Test and Statistics
The internal status of the reader can be accessed in COM interfaces giving
the following command string through a Terminal Emulator program:
$S,yX,s[CR](corded reader only).

Datalogic PowerScan PD9530 Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Tilt reading angle	0 - 360 °
Pitch reading angle	-40 - 40 °
Linear (1D) barcodes supported	-
Standard interfaces	RS-232, USB, Keyboard wedge
Connectivity technology	Wired
Product color	Black, Yellow
International Protection (IP) code	IP65
Input voltage	5 V
Power consumption	350 mA
Power source type	DC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Cables included	No

Weight and Dimensions

Depth	110 mm
Width	74 mm
Height	212 mm
Weight	330 g
