Datalogic PowerScan PD9530 User Manual

Technical Specifications
320 PowerScan™ PD9530/PBT9500/PM9500
Error Codes
Upon startup, if the reader sounds a long tone, this means the reader has
not passed its automatic Selftest and has entered FRU (Field Replaceable
Unit) isolation mode. If the reader is reset, the sequence will be repeated.
Press and release the trigger to hear the FRU indication code.
The following table describes the LED flashes/beep codes as
sociated with an
error found.
NUMBER OF
LED FLASHES/
BEEPS
Error CORRECTIVE ACTION
1 Configuration
Contact Helpdesk for
assistance
2 Interface PCB
6 Digital PCB
11 Imager
Base Station Indications (Cordless Models ONLY)
Base Station Button Indicators
BUTTON PUSH
EVENT
CORDLESS
RED
INDICATOR(**)
GREEN
INDICATOR(**)
Push at power-up
force device connection
(Ala
ddin)
Off
Slow blink
Fast blink
< 5 sec Paging Off Fast blink
5 to 10 sec Unlink (Only Bluetooth) Off Slow blink
Programming Mode Indications (continued)
INDICATION DESCRIPTION LED BEEPER
Label Program-
ming Mode Accep-
tance of
Programming
Con
figuration option(s)
have be
en successfully
programmed via labels
and the reader has exited
Programming Mode.
N/A
Reader sounds one
high frequency
beep
and 4 low fre-
quency beeps fol-
lowed by reset
beeps.
Label Program-
ming Mode Cancel
Item
Entry
Cancel label has been
sc
anned.
N/A
Reader sounds two
ti
me
s at low fre-
quency and current
volu
me.

Datalogic PowerScan PD9530 Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Tilt reading angle	0 - 360 °
Pitch reading angle	-40 - 40 °
Linear (1D) barcodes supported	-
Standard interfaces	RS-232, USB, Keyboard wedge
Connectivity technology	Wired
Product color	Black, Yellow
International Protection (IP) code	IP65
Input voltage	5 V
Power consumption	350 mA
Power source type	DC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Cables included	No

Weight and Dimensions

Depth	110 mm
Width	74 mm
Height	212 mm
Weight	330 g
