Datalogic PowerScan PD9530 User Manual

Product Reference Guide 313
Appendix A
Technical Specifications
The tables that follow contain Physical and Performance Characteristics,
User Environment and Regulatory information.
Table 53 provides Standard
Cable Pinouts.
Table 52. Technical Specifications
Item Description
Physical Characteristics
Dimensions
Height: 212 mm
Length: 110 mm
Width: 74 mm
Weight (without cable) 330 gr (without cable)
Electrical Characteristics
PD9530 models
Voltage & Current
PD9530/
PD9530-HP
PD9530-HPE PD9530-DPM
Input Voltage 5 VDC +/- 5% 10 to 30 VDC 5 VDC +/- 5%
Input Current
Operating (typical): 335 mA 135 mA @ 10V 350 mA
Operating (max): 475 mA 300 mA @ 10V 480 mA
Idle/Standby (typical) 180 mA 60 mA @ 10V 120 mA
PBT9500 and PM9500 models
Battery Type Li-Ion battery pack
Charge time for full
charge fro
m full dis-
charge
4 hours with external power supply adapter
a
a. Charge Times are much lower when battery is within daily typical operating condition.
Typical 10 hours with Host power (in this case no supply
adapter is needed)
a
Operating autonomy
(continuous reading)
30,000 reads (typical)
Cradle consumption and
DC in
put supply range
Volt 10-30 VDC; Power <8W
b
b. Typical input current measured under factory default configuration.
;
Max 500 mA when in host/bus powered mode
b
.

Datalogic PowerScan PD9530 Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Tilt reading angle	0 - 360 °
Pitch reading angle	-40 - 40 °
Linear (1D) barcodes supported	-
Standard interfaces	RS-232, USB, Keyboard wedge
Connectivity technology	Wired
Product color	Black, Yellow
International Protection (IP) code	IP65
Input voltage	5 V
Power consumption	350 mA
Power source type	DC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Cables included	No

Weight and Dimensions

Depth	110 mm
Width	74 mm
Height	212 mm
Weight	330 g
