Delta AS132P-A User Manual

9.3.2 EtherNet/IP Specification
Item
AS300 AS200 / AS100 AS-FEN02
Scanner Adapter Scanner Adapter Adapter
General
Device type
Scanner / Adapter Adapter
Topology type
Star topology Star, linear topologies
CIP Network
I/O
Connection
CIP connection
number
(data exchange)
32 8 16 8 8
TCP connection
number
16
(Clients + Servers)
8
(Clients + Servers)
8
Requested Packet
Interval (RPI)
5 ms – 1000 ms 1 ms – 1000 ms
Max. Transmission
Speed
3,000 pps 10,000 pps
Max. Data Length/per
transmission
500 bytes 200 bytes
Supported devices,
registers, and flags
FMV1.08
or
previous
versions:
D
FW V1.10
or later:
D/M*
D, X, Y,
SR
FMV1.08
or
previous
versions:
D
FW
V1.10 or
later:
D/M*
D, X, Y,
SR
D, X, Y, SR
CIP Network
Explicit
Message
Class 3
(Connected Type)
16 8 8 8 8
UCMM
(Non-Connected
Type, only uses TCP
connections)
Total 16
(for all connection
types)
Total 8
(for all connection
types)
Total 8
(for all connection
types)
CIP Objects
Identity Object (16#01)
Message Router Object (16#02)
Assembly Object (16#04)
Connection Manager Object (16#06)
Port Object (16#F4)
TCP/IP Interface Object (16#F5)
