Delta AS132P-A User Manual

Create
Projec tISPSoft
Open
HWC ONFI G
Set up
IP Address
Dow nload
HWC ONFI G
9.4.2.2 Set the IP Address (Static IP)
 Steps to set the IP address
When using an EIP product with a static IP address, set up the IP address in HWCONFIG in ISPSoft. The following
example uses the AS Series.
1. Configure the network parameters
 Double-click the AS Series module in HWCONFIG to see the Edit Area.
 On the Ethernet Port Basic Setting tab, set the IP address and then click OK.
2. Save and download the settings from HWCONFIG: on the File menu click Save to save the settings and then
click Download button on the toolbar.
Send Quote Requests to info@automatedpt.com
Call +1(800)985-6929 To Order or Order Online At Deltaacdrives.com
Send Quote Requests to info@automatedpt.com
Call +1(800)985-6929 To Order or Order Online At Deltaacdrives.com

Delta AS132P-A Specifications

General

Brand	Delta
Model	AS132P-A
Category	Network Hardware
Language	English
