Ducati MONSTER 696 User Manual

Tyres
Front tyre pressure:
2.25 bar - 2.29 kg/sq. cm
Rear tyre pressure:
2.50 bar - 2.55 kg/sq. cm
As tyre pressure is affected by changes in
temperature and altitude; check and adjust them
whenever you are riding in areas where there are
large variations in temperature or altitude.
Important
Check and adjust the pressures with the tyres
cold. To avoid front wheel rim distortion, when riding
on bumpy roads, increase tyre pressure by 0.2 - 0.3
bar.
REPAIRING OR REPLACING TYRES
In the event of a tiny puncture, tubeless tyres will take
a long time to deflate, as they tend to keep air inside.
If you find low pressure on one tyre, check the tyre
for punctures.
Warning
Punctured tyres must be replaced. Replace
tyres with recommended standard tyres only. Be
sure to tighten the valve caps securely to avoid leaks
when riding. Never fit tyres with inner tubes, as these
can cause the tyre to burst suddenly, with possibly
serious consequences for the rider and passenger.
After replacing a tyre, the wheel must be balanced.
Warning
Do not remove or shift the wheel balancing
weights.
138

Ducati MONSTER 696 Specifications

General

Displacement	696 cc
Bore x Stroke	88 x 57.2mm
Compression Ratio	10.7:1
Power	80 hp (59 kW) @ 9000 rpm
Transmission	6-speed
Frame	Tubular steel Trellis frame
Front Brake	2 x 320 mm discs, 4-piston radial calipers
Rear Brake	245 mm disc, 2-piston caliper
Seat Height	770mm (30.3 in)
Engine Type	L-Twin, 2 valves per cylinder Desmodromic
Torque	69 Nm (51 lb-ft) @ 7750 rpm
Fuel System	Electronic fuel injection, 45 mm throttle body
Exhaust	2-1-2 system with catalytic converter and lambda probe
Front Suspension	43 mm upside-down forks
Rear Suspension	Progressive with preload and rebound adjustable monoshock
Dry Weight	161 kg (355 lb)
Fuel Capacity	15 L (3.9 US gal)
