Back-lighting setting
This function allows dashboard backlighting power
setting.
To set the backlighting, access the "LIGHT SET" page
of the menu.
Press the switch (1Fig. 9), in position B “
” for 3
seconds in this page to access the setup mode and
the following pages will be displayed in sequence:
- page 1 - “LIGHT MAX” setting:
This page sets backlighting to maximum
brightness; press switch (1Fig. 9), in position B
“ ” to go to page 2.
- page 2 - “LIGHT MID” setting:
This page reduces the backlighting by
approximately 30% relative to maximum
brightness; press switch (1Fig. 9), in position B
“
” to go to page 3.
- page 3 - “LIGHT MIN” setting:
This page reduces the backlighting by
approximately 70% relative to maximum
brightness; press switch (1Fig. 9), in position B
“ ” to go to page 1.
B= ON for 3 secs.
Press B
Press B
Press B
B= ON for
3 secs.
B= ON for
3 secs.
B= ON for
3 secs.
Fig. 23
42

Ducati MONSTER 696 Specifications

General

Displacement	696 cc
Bore x Stroke	88 x 57.2mm
Compression Ratio	10.7:1
Power	80 hp (59 kW) @ 9000 rpm
Transmission	6-speed
Frame	Tubular steel Trellis frame
Front Brake	2 x 320 mm discs, 4-piston radial calipers
Rear Brake	245 mm disc, 2-piston caliper
Seat Height	770mm (30.3 in)
Engine Type	L-Twin, 2 valves per cylinder Desmodromic
Torque	69 Nm (51 lb-ft) @ 7750 rpm
Fuel System	Electronic fuel injection, 45 mm throttle body
Exhaust	2-1-2 system with catalytic converter and lambda probe
Front Suspension	43 mm upside-down forks
Rear Suspension	Progressive with preload and rebound adjustable monoshock
Dry Weight	161 kg (355 lb)
Fuel Capacity	15 L (3.9 US gal)
