Service menu - unit of measurement (UNIT
SET)
This function allows you to select the units of
measurement displayed on the instrument panel.
To enter the service menu press and hold switch
(1Fig. 9) in position A “
" while turning the ignition
key from "Off" to "On".
Note
Within this MENU all other functions are
excluded and motorcycle starting is disabled.
The first function displayed is “Immobilizer
Reprogramming” (00000 PRO), press switch
(1Fig. 9) in position A “ “ to display the other
function of the service menu “UNIT SET”.
Now press the switch (1Fig. 9), in the position B
“
” for 3 seconds.
Each time you press switch (1Fig. 9), in the position
B " ", the instrument panel scrolls through the
following sequence of options, which flash on the
display:
UNIT OF MEASUREMENT
Country
standard
Speed Air temperature
Odometer/
trip meters
EU Km/h °C Km
EN mph °C miles
USA mph °F miles
CND Km/h °C Km
FRA Km/h °C Km
JAP Km/h °C Km
ECU Id.
The instrument panel sets units of
measurement according to ECU infor-
mation.
If you press the switch (1Fig. 9), in position B " " for
3 seconds, the option currently displayed will be
saved to memory and the word “MEM” will appear.
Upon the following Key-On the instrument panel will
be set to the new settings.
70

Ducati MONSTER 696 Specifications

General

Displacement	696 cc
Bore x Stroke	88 x 57.2mm
Compression Ratio	10.7:1
Power	80 hp (59 kW) @ 9000 rpm
Transmission	6-speed
Frame	Tubular steel Trellis frame
Front Brake	2 x 320 mm discs, 4-piston radial calipers
Rear Brake	245 mm disc, 2-piston caliper
Seat Height	770mm (30.3 in)
Engine Type	L-Twin, 2 valves per cylinder Desmodromic
Torque	69 Nm (51 lb-ft) @ 7750 rpm
Fuel System	Electronic fuel injection, 45 mm throttle body
Exhaust	2-1-2 system with catalytic converter and lambda probe
Front Suspension	43 mm upside-down forks
Rear Suspension	Progressive with preload and rebound adjustable monoshock
Dry Weight	161 kg (355 lb)
Fuel Capacity	15 L (3.9 US gal)
