Ducati MONSTER 696 User Manual

Electrical system
The main components of the electric system are:
HEADLIGHT:
high beam type: H7 (12 V-55 W).
low beam type: H1 (12 V-55 W).
parking light type: LED 13.5V 3.2W/0.1W.
Electrical controls on handlebars:
Turn indicators:
bulbs type: 12 V-10 W.
Horn.
Stop light switches.
Battery, 12 V-10 Ah.
Generator 12V-480W.
ELECTRONIC VOLTAGE RECTIFIER, protected with
a 30 A fuse located to the side of the control unit
(11,Fig. 119) - (11,Fig. 120).
Starter motor, 12 V-0.7 kW.
Tail light and brake signal: LED.
Number plate light
bulb type: C5W (12 V-5W).
Note
To replace the bulbs, refer to the paragraph
“Changing bulbs”.
Fuses
The electrical system components are protected by
eight fuses located in the fusebox. Only six fuses are
connected to the system, two are spares.
Refer to the table below to identify the circuits
protected by the various fuses and their ratings.
Key to the fusebox
Pos El. item Rat.
1 Key ON 10 A
2 Side lights, high/low beam 15 A
3 El. item 15 A
4 Dashboard 5 A
5 Injection 20 A
6 ECU 5 A
7 Spare 20 A
8 Spare 15 A
162

Ducati MONSTER 696 Specifications

General

Displacement	696 cc
Bore x Stroke	88 x 57.2mm
Compression Ratio	10.7:1
Power	80 hp (59 kW) @ 9000 rpm
Transmission	6-speed
Frame	Tubular steel Trellis frame
Front Brake	2 x 320 mm discs, 4-piston radial calipers
Rear Brake	245 mm disc, 2-piston caliper
Seat Height	770mm (30.3 in)
Engine Type	L-Twin, 2 valves per cylinder Desmodromic
Torque	69 Nm (51 lb-ft) @ 7750 rpm
Fuel System	Electronic fuel injection, 45 mm throttle body
Exhaust	2-1-2 system with catalytic converter and lambda probe
Front Suspension	43 mm upside-down forks
Rear Suspension	Progressive with preload and rebound adjustable monoshock
Dry Weight	161 kg (355 lb)
Fuel Capacity	15 L (3.9 US gal)
