Ducati MONSTER 696 User Manual

Erase DDA
This function deletes all data from the DDA: the data
logger must be connected to vehicle wiring.
To erase data, enter the menu page "Erase DDA".
If you press switch (1Fig. 9), in position B “
“ for 3
seconds and the DDA is not acquiring data, the
message “WAIT…” is shown on the display for 10
seconds After 10 seconds, the message “ERASE
OK” appears for 3 seconds, to confirm that the data
has been deleted.
If switch (1Fig. 9), is pressed in the B “ “ position
for 3 seconds while the DDA data logger is acquiring
data, the data logger memory is not erased and the
display shows message "FAIL" for 3 seconds.
50

Ducati MONSTER 696 Specifications

General

Displacement	696 cc
Bore x Stroke	88 x 57.2mm
Compression Ratio	10.7:1
Power	80 hp (59 kW) @ 9000 rpm
Transmission	6-speed
Frame	Tubular steel Trellis frame
Front Brake	2 x 320 mm discs, 4-piston radial calipers
Rear Brake	245 mm disc, 2-piston caliper
Seat Height	770mm (30.3 in)
Engine Type	L-Twin, 2 valves per cylinder Desmodromic
Torque	69 Nm (51 lb-ft) @ 7750 rpm
Fuel System	Electronic fuel injection, 45 mm throttle body
Exhaust	2-1-2 system with catalytic converter and lambda probe
Front Suspension	43 mm upside-down forks
Rear Suspension	Progressive with preload and rebound adjustable monoshock
Dry Weight	161 kg (355 lb)
Fuel Capacity	15 L (3.9 US gal)
