Ducati MONSTER 696 User Manual

Maintenance
Scheduled maintenance chart: operations to be performed by the Dealer
List of operations and type of intervention
[set mileage (km/mi) or time interval *]
Km. x1000
1 12 23 36 48 60
mi. x1000 0.6 7.5 15 22.5 30 37.5
Months
6 12 24 36 48 60
Change engine oil
Change engine oil filter
Clean engine oil filter at intake
Check the engine oil pressure
Check/adjust the valve clearances (1)
Check the tension of the timing belts (1)
Replace the timing belts
Check and clean the spark plugs. Replace if necessary
Check and clean air filter (1)
Change the air filter
Check throttle body synchronisation and idling (1)
Check brake and clutch fluid level
Change brake and clutch fluid
Check and adjust brake and clutch controls
148

Ducati MONSTER 696 Specifications

General

Displacement	696 cc
Bore x Stroke	88 x 57.2mm
Compression Ratio	10.7:1
Power	80 hp (59 kW) @ 9000 rpm
Transmission	6-speed
Frame	Tubular steel Trellis frame
Front Brake	2 x 320 mm discs, 4-piston radial calipers
Rear Brake	245 mm disc, 2-piston caliper
Seat Height	770mm (30.3 in)
Engine Type	L-Twin, 2 valves per cylinder Desmodromic
Torque	69 Nm (51 lb-ft) @ 7750 rpm
Fuel System	Electronic fuel injection, 45 mm throttle body
Exhaust	2-1-2 system with catalytic converter and lambda probe
Front Suspension	43 mm upside-down forks
Rear Suspension	Progressive with preload and rebound adjustable monoshock
Dry Weight	161 kg (355 lb)
Fuel Capacity	15 L (3.9 US gal)
