Ducati MONSTER 696 User Manual

Transmission
Wet clutch controlled by the lever on left-hand side
of the handlebar.
Drive is transmitted from engine to gearbox main
shaft via spur gears.
Engine sprocket/clutch gearwheel ratio: 33/61
6-speed gearbox ; with constant mesh gears,
gearchange pedal on left.
Gearbox output sprocket/rear chain sprocket ratio:
15/39
Total gear ratios:
1
st gear
13/32
2
nd gear
18/30
3
rd gear
21/28
4
th gear
23/26
5
th gear
22/22
6
th gear
26/24
Drive chain from gearbox to rear wheel:.
Make: DID
Type: 620 V6
Size: 5/8” x 1/4”
Links: 107+ 1 open
Important
The above gear ratios are the homologated ones
and under no circumstances must they be modified.
Warning
If the rear sprocket needs replacing, contact a
Ducati Dealer or authorised Service Centre.
Incorrect replacement of this component could
seriously endanger rider and passenger safety and
cause irreparable damage to the motorcycle.
159

Ducati MONSTER 696 Specifications

General

Displacement	696 cc
Bore x Stroke	88 x 57.2mm
Compression Ratio	10.7:1
Power	80 hp (59 kW) @ 9000 rpm
Transmission	6-speed
Frame	Tubular steel Trellis frame
Front Brake	2 x 320 mm discs, 4-piston radial calipers
Rear Brake	245 mm disc, 2-piston caliper
Seat Height	770mm (30.3 in)
Engine Type	L-Twin, 2 valves per cylinder Desmodromic
Torque	69 Nm (51 lb-ft) @ 7750 rpm
Fuel System	Electronic fuel injection, 45 mm throttle body
Exhaust	2-1-2 system with catalytic converter and lambda probe
Front Suspension	43 mm upside-down forks
Rear Suspension	Progressive with preload and rebound adjustable monoshock
Dry Weight	161 kg (355 lb)
Fuel Capacity	15 L (3.9 US gal)
