Ducati MONSTER 696 User Manual

ABS disabling
This function disables the ABS control unit (on ABS
version only).
Warning
This operation must be carried out with the
vehicle stopped (key ON).
To disable the ABS control unit, access the menu on
the "DISAB ABS” page and hold down switch
(1Fig. 9), in position B “
“ for 3 seconds.
At the end of the 3 seconds, the flashing ABS light
(10Fig. 3), on the instrument panel indicates the
disabling.
From this moment, the ABS control unit is disabled;
it is automatically restarted at the next Key-Off / Key-
On.
At the next Key-On the instrument panel indicates
that it is operative by keeping the ABS light
(10Fig. 3), off.
If there are problems with the ABS system, the
instrument panel indicates its malfunction by keeping
the ABS light (10Fig. 3), on steady, the EOBD
light( 8Fig. 3), on steady and the ABS error in the
menu.
Fig. 29
Important
This indicator is activated only at a speed above
or equal to 10 km/h; at a speed lower than 10 km/h
the ABS control unit does not perform the
diagnostics.
52

Ducati MONSTER 696 Specifications

General

Displacement	696 cc
Bore x Stroke	88 x 57.2mm
Compression Ratio	10.7:1
Power	80 hp (59 kW) @ 9000 rpm
Transmission	6-speed
Frame	Tubular steel Trellis frame
Front Brake	2 x 320 mm discs, 4-piston radial calipers
Rear Brake	245 mm disc, 2-piston caliper
Seat Height	770mm (30.3 in)
Engine Type	L-Twin, 2 valves per cylinder Desmodromic
Torque	69 Nm (51 lb-ft) @ 7750 rpm
Fuel System	Electronic fuel injection, 45 mm throttle body
Exhaust	2-1-2 system with catalytic converter and lambda probe
Front Suspension	43 mm upside-down forks
Rear Suspension	Progressive with preload and rebound adjustable monoshock
Dry Weight	161 kg (355 lb)
Fuel Capacity	15 L (3.9 US gal)
