Ducati MONSTER 696 User Manual

“TRIP” mileage indicator
This function shows the distance travelled since the
trip meter was last reset.
Holding button 1page 27 pressed in position B
“
“ for 3 seconds when this function is displayed
resets the trip meter.
When the reading exceeds 999.9, distance travelled
is reset and the meter automatically starts counting
from 0 again.
EU, CND, FRA, JAP versions
UK, USA versions
Fig. 12
31

Ducati MONSTER 696 Specifications

General

Displacement	696 cc
Bore x Stroke	88 x 57.2mm
Compression Ratio	10.7:1
Power	80 hp (59 kW) @ 9000 rpm
Transmission	6-speed
Frame	Tubular steel Trellis frame
Front Brake	2 x 320 mm discs, 4-piston radial calipers
Rear Brake	245 mm disc, 2-piston caliper
Seat Height	770mm (30.3 in)
Engine Type	L-Twin, 2 valves per cylinder Desmodromic
Torque	69 Nm (51 lb-ft) @ 7750 rpm
Fuel System	Electronic fuel injection, 45 mm throttle body
Exhaust	2-1-2 system with catalytic converter and lambda probe
Front Suspension	43 mm upside-down forks
Rear Suspension	Progressive with preload and rebound adjustable monoshock
Dry Weight	161 kg (355 lb)
Fuel Capacity	15 L (3.9 US gal)
