Ducati MONSTER 696 User Manual

Tank filler plug
OPENING
Lift the protection lid (1) and fit the ignition key into
the lock. Turn the key clockwise 1/4 turn to unlock.
CLOSING
Refit the plug with the key in it and push it down into
its seat. Turn the key counter-clockwise to the initial
position and remove it. Close the lock protection lid
(1).
Note
The plug can only be closed with the key in.
Warning
Always make sure you have properly refitted
and closed the plug after refuelling.
1
OPEN
0
1/4
Fig. 49
85

Ducati MONSTER 696 Specifications

General

Displacement	696 cc
Bore x Stroke	88 x 57.2mm
Compression Ratio	10.7:1
Power	80 hp (59 kW) @ 9000 rpm
Transmission	6-speed
Frame	Tubular steel Trellis frame
Front Brake	2 x 320 mm discs, 4-piston radial calipers
Rear Brake	245 mm disc, 2-piston caliper
Seat Height	770mm (30.3 in)
Engine Type	L-Twin, 2 valves per cylinder Desmodromic
Torque	69 Nm (51 lb-ft) @ 7750 rpm
Fuel System	Electronic fuel injection, 45 mm throttle body
Exhaust	2-1-2 system with catalytic converter and lambda probe
Front Suspension	43 mm upside-down forks
Rear Suspension	Progressive with preload and rebound adjustable monoshock
Dry Weight	161 kg (355 lb)
Fuel Capacity	15 L (3.9 US gal)
