Ducati MONSTER 696 User Manual

Check engine oil level
Check the engine oil level through the sight glass (1)
on the clutch cover.
Oil level must be checked with the motorcycle
perfectly upright and the engine cold.
Oil level should be between the marks near the sight
glass. If the level is low, top up with SHELL Advance
4T Ultra engine oil.
Remove the oil filler cap (2) and top up until the oil
reaches the required level.
Refit the filler plug (2).
Important
Engine oil and oil filters must be changed by a
Ducati Dealer or authorised Service Centre at the
intervals specified in the scheduled maintenance
table reported in the Warranty Booklet.
1
2
Fig. 112
141

Ducati MONSTER 696 Specifications

General

Displacement	696 cc
Bore x Stroke	88 x 57.2mm
Compression Ratio	10.7:1
Power	80 hp (59 kW) @ 9000 rpm
Transmission	6-speed
Frame	Tubular steel Trellis frame
Front Brake	2 x 320 mm discs, 4-piston radial calipers
Rear Brake	245 mm disc, 2-piston caliper
Seat Height	770mm (30.3 in)
Engine Type	L-Twin, 2 valves per cylinder Desmodromic
Torque	69 Nm (51 lb-ft) @ 7750 rpm
Fuel System	Electronic fuel injection, 45 mm throttle body
Exhaust	2-1-2 system with catalytic converter and lambda probe
Front Suspension	43 mm upside-down forks
Rear Suspension	Progressive with preload and rebound adjustable monoshock
Dry Weight	161 kg (355 lb)
Fuel Capacity	15 L (3.9 US gal)
