15.5 Replacing the light conductor
in the Scaler handpiece
The light conductor must be checked regularly
for light transmission. Over the course of time it
becomes opaque or takes on a milky colour. This
impairs its ability to function and means that it
needs to be replaced.
The light conductor can be sterilised sev-
eral times. As soon as it starts to become
opaque or take on a milky colour, light
transmission begins to decrease.
❯
Unscrew the cover.
❯
Disconnect the light conductor.
❯
Connect a new light conductor.
❯
Screw on the cover.
15.6 Replacing the sealing screw
The sealing screw in the adapter of the hand-
piece hose must be replaced 1x per year.
Unscrew the sealing screw:
❯
Unscrew the sealing screw by hand. If the
screw is stuck, use the combination wrench
from the service kit.
Screw in the sealing screw:
Never use the combination wrench to
screw in the sealing screw. If it is screwed
in with too much torque, this can cause
damage to the mixing chamber.
❯
Firmly tighten the sealing screw by hand.
Usage
60 9000-615-28L02 1903V004
EN
