15Service Guide: EFI Fiery Central integrated server
Replacing parts
Figure 3: Internal side view
1 Power supply 6 USB ports (x2) and scan port 11 Hard disk drive in bracket
2 Motherboard 7 CPU cooling assembly 12 Front fan
3 Network port 8 DIMM slots
4 DVI port 9 DVD drive
5 USB ports (x2) 10 Removable drive (option)
Note: Cables, user interface board (UIB), and front panel USB ports are not shown.
9
1
2
5
6
4
7
8
3
10
11
12
