37Service Guide: EFI Fiery Central integrated server

Replacing parts

1 Prepare the CPU cooling assembly for installation.

• Make sure that the motherboard is placed on a padded, static-free work surface.

• Apply a fresh thermal compound square, as described in the note above.

• Align the cooling assembly so that when it is installed, the fan cable easily reaches the CPU fan power connector

CPU FAN on the motherboard.

2 Place the cooling assembly on the CPU.

• Make sure that the thermal pad on the underside of the heatsink is positioned on top of the CPU.

Be sure to remove any protective material that may be covering the surface of the thermal pad. Otherwise the

CPU may overheat.

• Align the four screws with the four screw posts.

Tighten the screws. Partially tighten all the screws before tightening any one screw all the way.

3 Connect the CPU fan cable to the motherboard connector CPU FAN.

4 If you installed a new CPU, make sure to reset the time and date in Setup (see Configure Help for more

information).

5 Reassemble the FC integrated server and verify its functionality (see page 54).

Battery

The battery on the motherboard is located at BT1. To replace it, use a 3V manganese dioxide lithium coin cell battery

(Sony CR2032 or equivalent).

ACHTUNG: Es besteht Explosionsgefahr, wenn die Batterie durch eine Batterie falschen Typs ersetzt wird. Als Ersatz

dürfen nur vom Hersteller empfohlene Batterien gleichen oder ähnlichen Typs verwendet werden. Verbrauchte

Batterien müssen entsprechend den jeweiligen gesetzlichen Bestimmungen entsorgt werden.

ATTENTION: Il y a risque d’explosion si la pile est remplacée par un modèle qui ne convient pas. Remplacez-la

uniquement par le modèle recommandé par le constructeur. Débarrassez-vous des piles usées conformément aux

réglementations locales en vigueur.

ADVARSEL!: Litiumbatteri - Eksplosionsfare ved fejlagtig håndtering. Batteriet må kun udskiftes med et andet batteri

af samme fabrikat og type. Brugte batterier skal bortskaffes i henhold til gældende regler.

Important: If you are installing a new CPU, secure slack in the fan cable using a tie-wrap. The tie-wrap

prevents the fan cable from interfering with the CPU fan. Also, make sure the connector on the cable is

securely connected to the motherboard.

Warning: There is danger of explosion if the battery is replaced with an incorrect type. Replace it only with the

same type recommended by the manufacturer. Dispose of used batteries according to local regulations.
