66Service Guide: EFI Fiery Central integrated server
Troubleshooting
Normal startup sequence
When you power on or reboot the FC integrated server, the system runs a startup routine that takes about three
minutes. If problems occur during startup and rebooting does not solve the problem, use Table 2 on page 68 to
troubleshoot the system.
The hard disk drive required is:
• Present
• Correctly installed
• Not visibly damaged
• Jumpered as the master (primary) according to label
Hard disk drive data cable is:
• Present
• Firmly connected to motherboard connector SATA 2
• Not visibly damaged
Hard disk drive, page 43
The drive required is:
• Present
• Correctly installed
• Not visibly damaged
• Jumpered as the master (secondary) according to label
• Activity LED lights on power up
DVD drive SATA cable is:
• Firmly connected to motherboard SATA 1
• Not visibly damaged
DVD drive, page 52
Each cable required is:
• Present
• The correct type
• Installed in the correct connector
• Well-seated
• Not visibly damaged (including connectors)
UIB cable, page 23
Hard disk drive data cable, page 43
DVD drive power and data combination cable,
page 52
Power cable(s), page 40
If included in the system, the required mouse, monitor, and keyboard are
present and appear undamaged. The mouse and keyboard are connected to
the correct ports on the FC integrated server connector panel.
The cables required are:
• Present
• Installed in the correct connector
• Well-seated
• Not visibly damaged (including connectors)
• Mouse (if applicable)
• Monitor (if applicable)
• Keyboard (if applicable)
• Monitor power cord (not pictured)
Table 1: Verifying the system (Continued)
Conditions to verify Part and additional page references
