FLEX-6000 Signature Series – Maestro User Guide

 Load SO2R_TX2 Transmit profile. (This Transmit profile is now automatically linked to ANT2)

 Set Slice A as the transmit Slice. (This loads the SO2R_TX1 Transmit profile)

 Change Slice A TX ANT to ANT2. (This loads the SO2R_TX2 Transmit profile)

To associate a Transmit profile with a TX antenna, select the TX Antenna you wish to associate in

the transmit Slice, then load or save a Transmit profile using the Profiles control panel in the Main

Menu, or select an existing Transmit profile using the menu.

Each Transmit profile saves a set of power settings, one setting for each band. To save power

settings for each band, select the Transmit profile from the drop-down menu, then tune to each

band and adjust the power settings. As the adjustments are made, an asterisk should appear

before the Transmit profile name in the drop-down menu, indicating that the Transmit profile has

been modified. When all bands of interest have been set, save the modified Transmit profile using

the Profiles control panel in the Main Menu.

NOTE: If a Transmit profile is modified, the change will affect all Global profiles with which the

Transmit profile is associated.

16.3 GLOBAL PROFILES

Global profiles manage the state of Panadapters and Slice Receivers and the layout of these

components on the Maestro display. Panadapter settings saved in Global profiles include the

number of Panadapters on the Maestro display, frequency ranges, bandwidth, and scaling and

display parameters. Slice Receiver parameters include the frequency, mode, MIC profile, RX and TX

filter settings, DAX channel, audio gain, and many others. See section 16.7, Comparing Profiles and

Persistence for details.

In addition, Global profiles also record the linking of each TX Antenna in each Slice to a Transmit

profile and each Slice Receiver’s mode. Invoking a Global profile therefore creates a set of

Panadapters and Slices, selects a Slice to control the transmitter, then invokes the Transmit profile

indicated by the selected TX antenna and the MIC profile. The selection of a different Slice to

control the transmitter may change the selected Transmit and MIC profiles depending on the TX

Antenna and Mode selected in the new TX Slice. Similarly, changes to the selected TX antenna or

mode within the transmit Slice may change the selected Transmit or MIC profiles.

To create or save a Global profile, configure all Panadapters and Slice Receivers to the desired

settings. TX Antennas and modes should be set to the desired values. Each TX Antenna that will be

used in the Global profile should be selected and then linked to a Transmit profile by selecting the

profile in the Profiles control panel. Select the mode and MIC profile in each Slice Receiver. When

these adjustments are complete, save the Global profile using the Profiles control panel.

Note: Changes made to Panadapters and Slices are not automatically saved to a loaded

Global profile. Changes to existing Global profiles can only be made by manually re-saving the

profile using the Profile control panel.

16.4 SAVING AND DELETING PROFILES

The Profiles control panel is reached by tapping on the Menu button on the main display, then on

the Profiles tab on the Main Menu. On the Profiles control panel tap the Global, TX, or MIC option
